About the #5

The #5 tee joins the end of one pipe to the middle of another at 90°. The through pipe stays continuous, which keeps rails and frames stiff and simple to lay out.

Like every Nu-Rail® fitting, it's cast from corrosion-resistant 535 aluminum-magnesium alloy and locks onto standard pipe with set screws. No welding, no threading, just a hex key. Loosen the screws and you can reposition it or take the whole structure apart later.

Where it's used

  • Posts meeting a continuous top rail
  • Mid-rails and shelf supports
  • Cross members in frames and racks

Sizes & options

Available for 3/4" to 2" IPS pipe. We stock the standard mill finish. Anodized fittings and stainless steel set screws for harsh environments are available on request; call 1-800-METPIPE.

Specifications

Figure
#5
Fits
3/4" to 2" IPS pipe
Casting
ASTM B26
Alloy
ASTM B179 535 Aluminum/Magnesium Alloy
Finish
Bright Burnished Mill Finish
Fastening
Set screw, hex key (no welding or threading)
  • Slip-on

Sizes & pricing

Item # Pipe size SKU Price Availability Add to cart
#5-5 3/4" 8754 $20.19 Only 8 left in stockMore on the way
#5-6 1" 8780 $24.02 In stock
#5-7 1-1/4" 8812 $28.96 In stock
#5-8 1-1/2" 8848 $37.14 BackorderShips in 2–3 weeks
#5-9 2" 8880 $58.47 In stock

Buying several sizes? Add each one right from this table. For job-site quantities, call 1-800-METPIPE.

How it goes together

  1. Slide it on Cut pipe to length and slip the fitting over the end. No threading.
  2. Position it Slide to height and set the angle before you lock it.
  3. Tighten the set screws Lock it with a hex key. Loosen it to adjust or take it apart later.
See all standard tees
